Engine and transmission |
Displacement |
49.5 ccm (3.02 cubic inches) |
Engine type |
Single cylinder, four-stroke |
Power output |
3.8 HP (2.8 kW)) @ 8000 RPM |
Fuel system |
Carburettor |
Cooling system |
Air |
Gearbox |
Automatic |
Transmission type |
Belt (final drive) |
Emission details |
Euro 3 |
Chassis, suspension, brakes and wheels |
Front suspension |
Telescopic fork |
Rear suspension |
Monoshock |
Front tire |
120/70-12 |
Rear tire |
120/70-12 |
Front brakes |
Single disc |
Diameter |
200 mm (7.9 inches) |
Rear brakes |
Expanding brake (drum brake) |
Diameter |
110 mm (4.3 inches) |
Physical measures and capacities |
Weight incl. oil, gas, etc |
116.0 kg (255.7 pounds) |
Seat height |
770 mm (30.3 inches) If adjustable, lowest setting. |
Overall height |
1190 mm (46.9 inches) |
Overall length |
1925 mm (75.8 inches) |
Overall width |
710 mm (28.0 inches) |
Fuel capacity |
8.50 litres (2.25 US gallons) |
Oil capacity |
0.80 litres (0.85 US quarts) |
